Application
Landfill Liner Systems
Bottom liners, leachate containment and final caps — a complete geosynthetic package for modern engineered landfills.
The engineering problem
A landfill must contain leachate for decades: aggressive chemistry, heavy waste loads, differential settlement of the subgrade, and puncture risk from drainage aggregate all attack the liner system. The design answer is a composite barrier — an impermeable membrane protected on both sides by cushion geotextile.
- Smooth HDPE geomembrane — the primary barrier: impermeable, chemically resistant to leachate, UV-stabilized for exposed caps, manufactured to GRI-GM13
- PP filament geotextile — cushion and protection above and below the membrane; 2–6.5 m widths cut seams on large cells
- PET staple geotextile — filtration layer in leachate collection drains — passes water, retains soil
Typical specifications
| Material | Available range |
|---|---|
| Smooth HDPE geomembrane | 0.5–3.0 mm, widths to 8 m, GRI-GM13 |
| PP filament geotextile | 50–1500 g/m², widths 2–6.5 m |
| PET staple geotextile | Needle-punched polyester, wide-width rolls |
Grade and thickness are selected per project design — send us your specification and we will match it.
Related products
Project reference
Landfill Project – Thailand
An anonymized landfill project in Thailand involving 500,000 m² of geomembrane and geotextile, together with 20 welding machines.
Building or expanding a landfill?
Send your liner schedule — we will quote the membrane + geotextile package together.
Request a Quote
