Application
Road & Railway
Subgrade separation, filtration and reinforcement for highways, railways and airport pavements — built to last under traffic.
The engineering problem
Traffic loads pump fine subgrade soils up into the aggregate base, destroying pavements from below; soft ground needs reinforcement before it can carry a road or track. A separation geotextile keeps layers apart while passing water — and wide rolls mean fewer overlaps and faster laying across long linear projects.
- PP filament geotextile — separation and reinforcement: high strength per gram, 2–6.5 m widths ideal for long road and rail sections; also used as anti-cracking interlayer in pavements
- PET staple geotextile — filtration and separation with low creep under sustained load — suits railway track beds
- Smooth HDPE geomembrane — waterproofing layer where subgrade waterproofing is specified
Typical specifications
| Material | Available range |
|---|---|
| PP filament geotextile | 50–1500 g/m², widths 2–6.5 m |
| PET staple geotextile | Needle-punched polyester, wide-width rolls |
| Smooth HDPE geomembrane | 0.5–3.0 mm, GRI-GM13 (where specified) |
Grade and thickness are selected per project design — send us your specification and we will match it.
Related products
Building a road or railway section?
Tell us the subgrade conditions and pavement structure — we will recommend the geotextile grade and quote.
